I/O Interfaces |
|
|
Power Output |
1x 5.5*2.1 mm DC plug (max. 12 VDC, 1A) |
|
Ethernet Ports |
1x 10/100 Mbps RJ45 PoE Input Port
1x 10/100 Mbps RJ45 Output Port |
|
|
|
|
Standards |
|
|
Network Standards |
IEEE 802.3i (10BASE-T Ethernet)
IEEE 802.3u (100BASE-TX Fast Ethernet)
IEEE 802.3x (Flow Control) |
|
PoE Standards |
IEEE 802.3af |
|
Network Media |
10BASE-T: UTP category 3, 4, 5 cable (max. 100 m)
100BASE-TX: UTP category 5 or above cable (max. 100 m) |
|
|
|
|
Environment |
|
|
Operating Temperature |
-10°C to 50°C |
|
Operating Humidity |
RH 10% to 90% (non-condensing) |
|
Storage Temperature |
-40°C to 85°C |
|
Storage Humidity |
RH 5% to 95% (non-condensing) |
|
|
|
|
General |
|
|
Power Supply |
max. 12 VDC, 1A |
|
Shell Material |
PC |
|
Dimension |
O23 x 100 mm (DxL) pigtail length 129 mm |
|
Net Weight |
45 g |
