Connector Type
|
|
|
Category
|
Cat 6
|
|
Connector
|
2x RJ45(8P8C) Female Ports
|
|
Shielding
|
Unshielded
|
|
|
|
|
Material
|
|
|
Housing Material
|
Polycarbonate + Nylon Waterproof Joint
|
|
Contact Material
|
Phosphor Bronze, Stamped Pin, Thickness = 0.35mm
|
|
Contact Surface Material
|
Gold Plating, thickness = 0.5U (0.5μin or 0.0127 µm)
|
|
|
|
|
Electrical Properties
|
|
|
Voltage/Current Rating
|
125 VAC / 1.5 A
|
|
Insulation Resistance
|
≥ 1000 MΩ
|
|
Contact Resistance
|
≤ 100 mΩ at 500 VDC
|
|
Dielectric Strength
|
750 VAC RMS, 60Hz, 1 minute
|
|
|
|
|
Mechanical Properties
|
|
|
Durability
|
≥ 750 mating cycles
|
|
Wire Gauge
|
AWG 22-26
|
|
|
|
|
Environment
|
|
|
Operating Temperature
|
-40°C to 70°C
|
|
Operating Humidity
|
RH 10% to 90% (non-condensing)
|
|
Storage Temperature
|
-40°C to 80°C
|
|
Storage Humidity
|
RH 5% to 96% (non-condensing)
|
|
|
|
|
General
|
|
|
Dimension
|
O20x118 mm (Diameter x Length)
|
|
Net Weight
|
29 g
|
