Connector Type
Category
Cat 6
Connector
2x RJ45(8P8C) Female Ports
Shielding
Unshielded
Material
Housing Material
Nylon PA66
Contact Material
Phosphor Bronze, Stamped Pin, Thickness = 0.35mm
Contact Surface Material
Gold Plating, thickness = 3U (3μin or 0.0762 µm)
Electrical Properties
Transmission Frequency
250 MHz
Voltage/Current Rating
125 VAC / 1.5 A
Insulation Resistance
≥ 1000 MΩ
Contact Resistance
≤ 100 mΩ at 500 VDC
Dielectric Strength
750 VAC RMS, 60Hz, 1 minute
Mechanical Properties
Durability
≥ 750 mating cycles
Wire Diameter
4 mm ≤ ODO ≤ 8 mm
Environment
Operating Temperature
-40°C to 70°C
Operating Humidity
RH 10% to 90% (non-condensing)
Storage Temperature
-40°C to 80°C
Storage Humidity
RH 5% to 96% (non-condensing)
General
Dimension
O22.5x108 mm (Diameter x Length)
Net Weight
25 g
Diagram
unit: mm
